StorePak™ NVMe SP306N-CCVPX
The SP306N-CCVPX StorePak™ is a removable single slot conduction-cooled 3U VPX storage module designed to be used either in conjunction with Critical I/O’s StoreEngine storage manager, or as a stand-alone Direct Attach Storage device. The StorePak™ is engineered for easy removal and replacement of on board storage since there are no cables to unplug to remove StorePak™. Specifically engineered for use in rugged embedded systems, StorePak's NVMe SSD storage provides unmatched functionality, 5 GB/s read/write performance, high capacity, and scalability with a small size, weight, and power (SWaP) footprint.
- Recording, DAS, NAS applications
- Rugged conduction cooled VPX
- SSD capacity of up to 12TB
- Easily removable SSD module
- Performance of up to 5 GB/s
- Seven PCIe Gen3 x4 backplane ports
- Highly scalable and expandable
| Base Model Number | Form Factor | Cooling | Extended Temp Available | Max Storage Capacity | Max Performance | Scalable | RAID | Removable Storage | Backplane Interfaces | Recording & Network File Services |
|---|---|---|---|---|---|---|---|---|---|---|
| SP306N-CCVPX | 3U CCVPX | Conduction | Yes | 12 TB | 5 GB/s | Yes | Host Based | Yes | 7x PCIe Gen3 x4/x8 | If used with StoreEngine |
| SP306N-VPX | 3U VPX | Air | Yes | 12 TB | 5 GB/s | Yes | Host Based | Yes | 7x PCIe Gen3 x4/x8 | If used with StoreEngine |
| SP306R-CCVPX | 3U CCVPX | Conduction | Yes | 6 TB | 2 GB/s | Yes | 0/1/10/1E Hardware Based | Yes | 6x PCIe Gen2 x4/x8 | If used with StoreEngine |
| SP306R-VPX | 3U VPX | Air | Yes | 6 TB | 2 GB/s | Yes | 0/1/10/1E Hardware Based | Yes | 6x PCIe Gen2 x4/x8 | If used with StoreEngine |
| SP606R-CCVPX | 6U CCVPX | Conduction | Yes | 46 TB | 2.5 GB/s | Yes | 0/1/10/1E Hardware Based | Yes | 6x PCIe Gen2 x4/x8 | If used with StoreEngine |
| SP606R-VPX | 6U VPX | Air | Yes | 46 TB | 2.5 GB/s | Yes | 0/1/10/1E Hardware Based | Yes | 6x PCIe Gen2 x4/x8 | If used with StoreEngine |
